Booster Sets
Max. Flow:
75m³/hr
Max. Head:
180m
Max. Temp:
100°C
Material:
Metal
Booster Sets
Our Booster Sets and integrated systems are meticulously built to meet diverse water boosting requirements. Designed to maintain consistent water pressure in lines or systems, these sets provides an ideal solution for addressing low water pressure, ensuring optimal performance in your water supply system. Our Booster Sets elevate the pressure and flow of your pump system, delivering significant enhancements to your operational performance. Equipped with a smart control system, the booster pumps activate seamlessly when low pressure is detected, promptly increasing pressure for continuous and steady fluid delivery.
Typical uses for our Booster Sets:
- Used to maintain constant water pressure in a line/system
- When the control system senses low pressure, the booster pumps turn on, increasing the pressure in the line
Features & Benefits
- Supports pressures up to 18 Bar
- Capable of handling flow rates up to 75m³/hr
- Single or multiple pump configurations available
- Options to choose between a pressure vessel or break tank based on specific requirements
- Dry run protection feature included, ensuring the longevity of your pumps
- No, basic or advanced speed control available for operational precision
- Capability for pump automation (on/off)
- Available in-tank booster systems
- Available with WRAS, Cat 5, KIWA 4 approvals, ensuring compliance with industry standards
- Options for tanks with low-level alarms
- Safety start/slow fill settings for enhanced safety
- Multiple mounting options including frame, compact or skid, catering to various installation needs
- Customisable manifolds to match pipework requirements, ensuring seamless integration
Components of Booster Sets
Our Booster Sets are customisable with many components available that can be added or removed to best suit your application needs. This includes pressure tanks, WRAS compliance and BMS integration as examples. Here’s a non-exhaustive list of the most basic components available:
- Booster Pump/s – typically Multistage Centrifugal Pumps, vertically and horizontally configurated
- Pressure Transducer – mounted on to a common outlet which monitors discharge pressure of the pumps
- Control Panel – the ‘brains’ of the set up. This takes the transducer readings and adjusts the pump speed to either increase or decrease pressure to ensure constant supply is provided
