Plastic Diaphragm Pump
Max. Flow:
49m³/hr
Max. Head:
80m
Max. Temp:
100°C
Material:
Plastic
Eco Friendly Plastic Diaphragm Pump
Our Eco-Friendly Plastic Diaphragm Pump, featuring Low Energy Air Pump (LEAP) technology, optimises energy usage, resulting in up to 70% energy savings for businesses. By precisely controlling airflow, this pump ensures peak performance and decreased operational expenses. This LEAP technology can be retrofitted to any Tapflo or comparable Air Operated Diaphragm Pump from other manufacturers on the market today, or it can be purchased as a complete pump unit. This technology enables Diaphragm Pumps to operate at a minimal 0.2 Bar compared to standard Diaphragm Pumps that begin operating at 1.2 Bar. This ensures smoother operation and minimises pulsations in the pump output. While applicable across the below industries, this technology truly excels in low-discharge pressure applications.
Typical industries for our Eco Friendly Plastic Diaphragm Pump:
- Chemical
- Industrial
- Oil & Gas
- Pulp & Paper
- Surface Treatment
Eco Friendly Plastic Diaphragm Pump (LEAP)
Eco Friendly Plastic Diaphragm Pump Demo
Features & Benefits
- Compatible with any Tapflo or comparable Air Operated Diaphragm Pump
- Can be retrofitted to existing pumps by replacing the centre-section
- Starts operation at 0.2 Bar
- Achieve up to 70% energy savings compared to standard Diaphragm Pumps
- Stall-proof design
- Air valve replacement in under 2 minutes
- Reduced pulsation
- Lapped spool and sleeve construction for the main air valve, extending life expectancy to over 200 million life cycles
- Single-seal construction reduces frictional losses
- Accurate monitoring of flow rate, preventing dry running, deadheading and facilitating batch dispensing
Specifications
| Materials | Aluminium, Cast Iron, PE, PTFE, Stainless Steel AISI 316L |
| Max Capacity | 820 l/min |
| Max Pressure | 160m |
| Self Priming | Yes |
| Max Solids Size | 100mm |
| Max Temperature | 100ºC |
| Viscosity | 0-200+ cSt |
